Specifications:
Model | M608FIRC-HS20X-Y7 |
Camera | |
Image Sensor | 1/2.8" Sony CMOS |
Effective Pixels | 8 megapixels |
Electronic Shutter | AUTO, 1/10s ~ 1/100000s |
Min. Illumination | 0.01Lux@F1.2(AGC ON) |
Day/Night | Auto/Color/(B/W)/Timing |
WDR | Digital WDR |
White Balance | Auto/Manual |
BLC /HLC | Support |
DNR | 2D/3D DNR |
Other | Image adjust , Flip |
Encode | |
Video Standard | H.265+/H.265/H.264/MJPEG |
Video Resolution | MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc. Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc. Third stream:1080P/720P/CIF@10fps |
Video Bitrates | 512Kbps - 12Mbps, VBR/CBR |
Audio Standard | G.711-u/G.711-a/AAC |
Two-way audio | Built-in Mic and speaker |
Smart Detection | Motion Detection |
IR Led | |
IR Led | 10pcs(6 dual-light Led + 4 laser IR led) |
IR Distance | 120-150 M |
Lens | |
Focal length | 4.7-94mm |
IRIS | F1.6-3.5 |
View angle | 64 - 2.9 ° |
Zoom | 20x optical zoom |
Other Function | |
High power PoE+, SD Slot, Reset button | |
PTZ | |
Pan/Tilt Range | Pan: 0° ~ 360°; Tilt: -5° ~ 90° |
Preset Point | 256 |
Control Speed | Pan: 0.5° ~60° /s; Tilt: 0.5° ~60° /s |
A-B Scanning | Support |
Auto Cruising | Support 8 groups patrol, Max. 16 presets in group |
Power on Action | Preset/Scan/Cruise |
Power-off Recovery | Support |
Smart Tracking | Human Detection Tracking together with patrol |
Network Services | |
Protocol | HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP, etc. |
P2P | Yes |
Web | IE, Firefox, Chrome, Edge, Safari |
Media | CMS, Android, IOS |
ONVIF | 17.06 compatible |
General | |
Network Port | 1-RJ45, 100Mbps, PoE+ 48V in |
Power Supply | 12 VDC ± 10% 3A |
Power Consumption | < 25 W |
Operating Temp. | -30℃-(+60)℃, 10%-90%RH |
Size | 7 inch |
Weight | |
