Technical Specifications:
Model | M608FIRC-HS20X-Y |
Camera | |
Image Sensor | 1/2.8" Sony CMOS |
Effective Pixels | 8 megapixels |
Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
Day/Night | Auto/Color/(B/W)/Timing |
WDR | Digital WDR |
White Balance | Auto/Manual |
BLC /HLC | Support |
DNR | 2D/3D DNR |
Other | AGC,Motion Detection,Privacy Mask,Flip,OSD overlay |
Encode | |
Video Standard | H.264/H.265 |
Video Resolution | Main Stream: 20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc. Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc. |
Video Bitrates | 512Kbps - 12Mbps, VBR/CBR |
Audio Standard | G.711-u/G.711-a |
Built-in Mic | Yes |
LEDs | |
LEDs | 4 PCS 4 PCS warm light & IR dual light 6 PCS Array IR LEDs |
LEDs Distance | Dual light distance 40-50 meters IR distance 80-100meters |
Lens | |
Focal length | 4.7-94mm |
IRIS | F1.6-3.5 |
View angle | 64 - 2.9 ° |
Zoom | 20x optical zoom |
Optional Function | |
PoE, human auto-tracking, Two-way Audio, SD card slot (Max. 256GB) | |
PTZ | |
Pan/Tilt Range | Pan: 0° ~ 360°; Tilt: -5° ~ 90° |
Preset Point | 128 |
Control Speed | Pan: 0.5° ~30° /s; Tilt: 0.5° ~30° /s |
A-B Scanning | Support |
Auto Cruising | Support 8 groups |
Power on Action | Preset/Scan/Cruise |
Power-off Recovery | Support |
Network Services | |
Protocol | HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
P2P | Yes |
Web | IE , Firefox (32bit esr), etc. |
Media | CMS, Android, IOS |
ONVIF | 17.06 compatible |
General | |
Network Port | 1-RJ45, 100Mbps, PoE 48V in |
Power Supply | 12 VDC ± 10% 2A |
Power Consumption | < 20 W |
Operating Temp. | -30℃-(+60)℃, 10%-90%RH |
Size | Φ137(mm)×234(mm) |
Weight | 2.3kg |
